Mercusys MW301R 300Mbps Wireless N Router
300Mbps, 2x5dBi fixed omni directional antennas, 2x10/100Mbps LAN ports, 1x10/100Mbps WAN port, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, 2.4GHz, CE, ROHS
29,00 KM
Opis proizvoda
Dimensions (W X D X H) | 114x94x26 mm |
---|---|
Wireless Security | WPA-PSK / WPA2-PSK |
Protocols | IPv4, IPv6 |
External Power Supply | 5VDC/0.6A |
Antenna Type | 2 x 5dBi fixed omni directional antennas |
Signal Rate | 11n: Up to 300Mbps (Dynamic)11g: Up to 54Mbps (Dynamic)11b: Up to 11Mbps (Dynamic) |
Button | RESET |
Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Frequency | 2.4 - 2.4835GHz |
Reception Sensitivity | 270M: -70dBm@10% PER130M: -74dBm@10% PER108M: -77dBm@10% PER54M: -76dBm@10% PER11M: -90dBm@8% PER6M: -92dBm@10% PER1M: -97dBm@8% PER |
Interfaces | 2 10/100Mbps LAN ports1 10/100Mbps WAN port |
Certifications | CE, ROHS |
Package Contents | 300Mbps Wireless N Router MW301RPower adapterQuick Installation GuideEthernet cable |
Environment | Operating temperature: 0⁰C ~ 40⁰C (32⁰F ~ 104⁰F)Storage temperature: -40⁰C ~ 70⁰C (-40⁰F ~ 158⁰F)Operating humidity: 10% ~ 90%, non-condensingStorage humidity: 5% ~ 90%, non-condensing |
Transmission Power | <20dBm |
Wireless Functions | WDS bridge |
WAN Type | Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
Management | Parental ControlAccess controlLocal managementRemote management |
DHCP | Server |
Port Forwarding | Virtual server, UPnP, DMZ |
Dynamic DNS | DynDNS、NO-IP |
Firewall Security | IP and MAC address binding |
Guest Network | 2.4GHz guest network |
